The Most Imitated Sprinkler on the Market Just Got Better
Durable: Designed to last longer in the field
Backed by an unprecedented 3 year warranty on materials, workmanship and performance
Saves Energy: 6 - 15 psi (0.41 - 1.03 bar)
Convenient: Protective shroud doubles as a nozzle carrier
senninger
森寧格是農業、園藝和工業應用優質灌溉解決方案的領先設計師和制造商。我們的產品旨在盡可能少地使用水和能源，以幫助灌溉者充分利用每一滴水。在全球50多個國家擁有超過50年的經驗。森寧格是灌溉行業最值得信賴的名字之一。
我們的產品在美國制造，確保最高質量標準得到遵守。產品在上架前，在現場和我們的設施中經過反復、嚴格的測試。這些測試程序和對細節的關注意味著我們的客戶可以依賴于他們對我們所有產品的一致性和質量要求。
I-WOB®2
Senninger has improved on the i-Wob? UP3? design with the next generation i-Wob2. Featuring a protective shroud that doubles as a nozzle carrier, the new i-Wob2 is capable of better withstanding harsh operating conditions. Senninger Wobblers are recognized across the globe for their ability to spread water in a highly uniform pattern resistant to wind-drift and evaporation.
Flows: 0.80 to 18.35 gpm (182 to 4168 L/hr) based on model
Pressures: 6 to 15 psi (0.41 to 1.03 bar)
- 保護罩保護噴頭的磨損表面，防止相鄰噴頭飛濺、沙礫和直接紫外線損傷
- 導流罩兼作噴嘴托架，使重新利用變得快速而容易
- 超低工作壓力6至15磅/平方英寸（0.41至1.03巴），省錢省電
- 有四種偏轉器型號，提供不同的液滴尺寸和軌跡
- 獨家低于噴嘴重量，無需更重的傳統落錘
- 以史無前例的材料、工藝和性能三年保修為后盾。
i-Wob2 - Black Deflector
Trajectory: Standard-Angle
Surface: 9-Grooves
Droplet Size: Medium Droplets
Ideal for: Silty & Loamy Soils
i-Wob®2 - Blue Deflector
Trajectory: Low-Angle
Surface: 9-Grooves
Droplet Size: Medium Droplets
Ideal for: Silty & Loamy Soils
i-Wob2 - Grey Deflector
Trajectory: Low-Angle
Surface: 6-Grooves
Droplet Size: Small Droplets
Ideal for: Tight, Clay Soils
i-Wob2 - White Deflector
Trajectory: Low-Angle
Surface: 6-Grooves
Droplet Size: Large Droplets
Ideal for: Sandy Soils
I-WOB2
*It is recommended that larger nozzle sizes be used only on soils that can handle higher application rates.
** Senninger recommends 10 psi for optimum performance; 6 psi can be used for nozzles #12 and larger.
*** For optimum performance, Senninger recommends the use of maximum spacing for 1-2 spans only.
Note: Always mount the i-Wob2 on a minimum of 2 ft reinforced flexible hose. The hose must be on the outlet end of any semi-rigid or rigid drop.
Keep i-Wobs above crop canopy when outlet spacing exceeds 10 ft This is especially important on high profile crops.
I-WOB2 (METRIC)
*It is recommended that larger nozzle sizes be used only on soils that can handle higher application rates.
** Senninger recommends 0.69 bar for optimum performance; 0.41 bar can be used for nozzles #12 and larger.
*** For optimum performance, Senninger recommends the use of maximum spacing for 1-2 spans only.
Note: Always mount the i-Wob2 on a minimum of 0.6 m reinforced flexible hose.The hose must be on the outlet end of any semi-rigid or rigid drop.
Keep i-Wobs above crop canopy when outlet spacing exceeds 3.0 m. This is especially important on high profile crops.
PIVOT WOBBLER COMPARISON
PIVOT WOBBLER COMPARISON (METRIC)
Magnum Weight
Senninger weights provide stability on drops for a number of pivot applicators. The weight’s easy-to-install design lets it remain on the applicator during nozzle changes.
Always be sure the weight is tightly threaded into the bottom of the i-Wob2 (140-inch-lbs torque recommended)
Pressure Regulators
Senninger pressure regulators control excessive and varying inlet pressures to a constant outlet pressure. They allow a system to maintain an accurate flow output at each sprinkler head to ensure proper distribution uniformity.
Recognizing the importance of maintaining correct system pressure and uniform distribution, Senninger offers various models to meet specific flow and installation requirements.
XI-WOB®
Ideal for installation on semi-rigid PE drops, steel drops, and flexible hose drops when used with the Magnum Weight.
Flows: 1.09 to 15.78 gpm (248 to 3584 L/hr) based on model
Pressures: 10 to 15 psi (0.69 to 1.03 bar)
- Senninger?Wobbler?技術產生低應用強度以保持土壤完整性
- 低壓運行省錢省力
- 根據所需的軌跡和液滴尺寸，提供三種不同的模型
- 材料、工藝和性能的兩年保修
- 易于更換UP3噴嘴-只需捏拉即可拆卸、放置并單擊即可重新安裝，易于識別顏色編碼，并保證五年內保持正確的孔尺寸
Model 610 (Blue)
Surface: 6-Grooves
Droplet Size: Medium Droplets
Model 615 (Black)
Trajectory: 15°
Surface: 6-Grooves
Droplet Size: Large Droplets
Model 910 (Grey)
Surface: 9-Grooves
Droplet Size: Small Droplets
XI-WOB
*It is recommended that larger nozzle sizes be used only on soils that are suited for higher application rates.
** For optimum performance, Senninger recommends the use of maximum spacing for 1-2 spans only.
Note: When outlet spacing exceeds 10 ft, keep Xi-Wobs above crop canopy. This is especially important on high profile crops. Not warranted for rigid installation on offsets or booms larger than 10.5 ft. Longer offsets and booms require a minimum of 2 ft reinforced flex hose.
XI-WOB (METRIC)
*It is recommended that larger nozzle sizes be used only on soils that are suited for higher application rates.
** For optimum performance, Senninger recommends the use of maximum spacing for 1-2 spans only.
Note: When outlet spacing exceeds 3.0 m, keep Xi-Wobs above crop canopy. This is especially important on high profile crops. Not warranted for rigid installation on offsets or booms larger than 3.2 m. Longer offsets and booms require a minimum of 0.61 m reinforced flex hose.
PIVOT WOBBLER COMPARISON
PIVOT WOBBLER COMPARISON (METRIC)
Magnum Weight
Senninger weights provide stability on drops for a number of pivot applicators. The weight’s easyto-install design lets it remain on the applicator during nozzle changes.
UP3 Dual Nozzle Carrier
To access the secondary nozzle, pinch and pull the nozzle from the applicator, flip the carrier over and click in the secondary nozzle. The carrier is marked to indicate high and low flow nozzles.
Pressure Regulators
Senninger pressure regulators control excessive and varying inlet pressures to a constant outlet pressure. They allow a system to maintain an accurate flow output at each sprinkler head to ensure proper distribution uniformity.
Recognizing the importance of maintaining correct system pressure and uniform distribution, Senninger offers various models to meet specific flow and installation requirements.
XCEL-WOBBLER® UP3 TOP
With the release of the Xcel-Wobbler? UP3 TOP featuring the convenient UP3 nozzle, Senninger is expanding its patented Wobbler technology. This innovative top-of-pipe product is designed specifically for low pressure to promote energy savings and produce a wind-resistant large droplet.
Flows: 0.80 to 14.98 gpm (182 to 3402 L/hr)
Pressures: 10 psi (0.69 bar)
- Senninger?Wobbler?技術在大面積濕潤區域提供卓越的均勻性
- 比其他噴水裝置更經濟
- 低壓操作可節省能源并提供更大的液滴尺寸
- 材料、工藝和性能的兩年保修
- 易于更換UP3噴嘴-只需捏拉即可拆卸、放置并單擊即可重新安裝，易于識別顏色編碼，并保證五年內保持正確的孔尺寸
Xcel-Wobbler UP3 TOP
Surface: 6-Grooves
Droplet Size: Large Droplets
XCEL-WOBBLER UP3 TOP
*It is recommended that larger nozzle sizes be used only on soils that can handle higher application rates.
XCEL-WOBBLER UP3 TOP (METRIC)
*It is recommended that larger nozzle sizes be used only on soils that can handle higher application rates.
PIVOT WOBBLER COMPARISON
PIVOT WOBBLER COMPARISON (METRIC)
Pressure Regulators
Senninger pressure regulators control excessive and varying inlet pressures to a constant outlet pressure. They allow a system to maintain an accurate flow output at each sprinkler head to ensure proper distribution uniformity.
Recognizing the importance of maintaining correct system pressure and uniform distribution, Senninger offers various models to meet specific flow and installation requirements.
LEPA Close Spacing
LEPA (Low Energy Precision Application) bubblers use less energy than conventional low-pressure sprinklers and can operate using fewer gallons per minute. There are two types of bubble heads available: one deposits water straight down into furrows and distributes water in a narrow stream that avoids wetting the foliage; the other deflects water down in a wide, dome-shaped pattern that gently distributes water without spraying. With LEPA heads, at least 20 percent more water reaches the soil than with conventional spray nozzles.
Flows: 0.27 to 18.35 gpm (61 to 4168 L/hr) Pressures: 6 to 15 psi (0.41 to 1.03 bar)
- 防風漂移損失
- 最小蒸發損失
- 野生植物
- 實現更均勻的根區覆蓋
- 能用淡水增加產量
- 低壓力系統可降低抽水成本
- 高低剖面作物理想
Shroud w/ Bubbler (beige)
Shroud w/ CM1 (red)
UP3 Bubbler Assembly
LOW ENERGY PRECISION APPLICATION
LEPA (Low Energy Precision Application) systems gently deliver water just 8 to 18 inches above the ground to combat wind-drift and prevent evaporation loss. Researchers and growers have found that with LEPA at least 20 percent more water reaches the soil compared to conventional spray nozzles.
LDN LEPA bubblers operate at low pressures ranging from 6 to 20 psi. They use less energy than conventional low-pressure sprinklers, and operate using fewer gallons per minute than conventional spray nozzles - approximately 0.27 to 21.18 gpm.
Magnum Weight
Senninger weights provide stability on drops for a number of pivot applicators. The weight’s easyto-install design lets it remain on the applicator during nozzle changes.
Pressure Regulators
Senninger pressure regulators control excessive and varying inlet pressures to a constant outlet pressure. They allow a system to maintain an accurate flow output at each sprinkler head to ensure proper distribution uniformity.
Recognizing the importance of maintaining correct system pressure and uniform distribution, Senninger offers various models to meet specific flow and installation requirements.
噴灌機配件
Goosenecks & Truss Rod Hose Slings
Goosenecks & Truss Rod Hose Slings
Goosenecks & Truss Rod Hose Slings
UP3 Dual Nozzle Fitting
UP3 DUAL NOZZLE CARRIER
BALL VALVE
WEIGHTS
ADAPTERS & FITTINGS
